CIMON PLC CM3-SB16MDTV

March 13, 2019 0

CIMON PLC

CM3-SB16MDTV

  • PID Control
    – Operates 32 LOOP PID without PID module.
  • I/O reservation
    – Scans module at designated slot.
    Refers to reservation function which writes a program without I/O change in case of expansion, damage or replacement.
  • Online Edit
    – Program can be edited while Run mode.

Description

  • 16Kpps High-Speed Counter (2 Channel) Built-in
    – 2PH. 2/4Multi. Input mode possible, Voltage input type (Open collector)
  • 100kpps 2axis Pulse Output built-in. (Positioning)
    – Pulse + Direction Output, Position/Speed/Speed-Position, Position-Speed Control.
  • Max. 3communications can work simultaneously. (USB, RS232, RS485)
    – CIMON HMI, MODBUS RTU/TCP, PLC Link, Protocol program(User protocol), Loader protocol, Remote access & up/download supported.
    (Only SB16MDTV support RS485.)
  • Memory (10K Step)
  • Data reserved in case of power loss
    – Built-in Flash memory enabling permanent backup of the program without any separate battery
