6AV2124-0GC01-0AX0 SIEMENS SIMATIC HMI TP700 Comfort,Comfort Panel (EC-0086)
SIEMENS
6AV2124-0GC01-0AX0
SIMATIC HMI TP700 Comfort,Comfort Panel
SIMATIC HMI TP700 Comfort, Comfort Panel, Touch operation, 7″
widescreen TFT display, 16 million colors, PROFINET interface,
MPI/PROFIBUS DP interface, 12 MB configuration memory,
Windows CE 6.0, configurable from WinCC Comfort V11
Description
General information
Product type designation | TP700 Comfort |
Display
Design of display | TFT |
Screen diagonal | 7 in |
Display width | 152.4 mm |
Display height | 91.4 mm |
Number of colors | 16 777 216 |
Resolution (pixels) | |
● Horizontal image resolution | 800 Pixel |
● Vertical image resolution | 480 Pixel |
Backlighting | |
● MTBF backlighting (at 25 °C) | 80 000 h |
● Backlight dimmable | Yes; 0-100 % |
Supply voltage
Type of supply voltage | DC |
Rated value (DC) | 24 V |
permissible range, lower limit (DC) | 19.2 V |
permissible range, upper limit (DC) | 28.8 V |
Input current
Current consumption (rated value) | 0.5 A |
Starting current inrush I²t | 0.5 A²·s |
Power
Active power input, typ. | 12 W |
Processor
Processor type | X86 |
Memory
Flash | Yes |
RAM | Yes |
Memory available for user data | 12 Mbyte |
